Manufacturer Info
Features
- Displays amperage from -500 to +500 Amps
- Displays voltage from 0 to 60 Volts in 0.01 Volt increments
- High and low voltage, audio and visual alarms
- Standard meter operates in negative side of circuit only. Shunt Shifter required for positive side installation such as alternators
- 3 levels of display brightness
- Programmable sleep mode blanks display for power conservation
- Splashproof front
- Includes 500 Amp shunt
- Cutout Templates
| Specifications | |
|---|---|
| Meter | CurrentVoltage |
| Alarms | High and low voltage |
| Input Voltage | 7-60V DC |
| Maximum Power Consumption | 1 Watt |
| Minimum Power Consumption | 0.60 Watt |
| Sleep Mode | Programmable |
| Weight | 1.10lb (0.5 kg) |
| Included | ||
|---|---|---|
| Qty | PN | Product |
| 1 | 8255 | DC Digital Current Shunt - 500A |
| Optional Accessories | |
|---|---|
| 8013 | Blank Meter Panel - Single |
| 1475 | Mounting Panel Single Meter |
