Features

• 300 watts of charging power
• Isolated DC DC Charger
• One, two or three bank charging
• Manual equalization mode
• Two or three stage charging profiles
• Low EMI
• 110 to 300 VDC inputs
• Adjustable float voltage
• Temperature compensation
• Three year warranty (parts & labor)
• Product Datasheet | Download
• Product Manual | Download

The traditional BCD310 series chargers feature 300 watts of precision charging power for 1, 2 or 3 banks of batteries at 12, 24, 32, 36, 48 or 72(rail) volts DC. Models are available to operate from 110, 250 or 300 volts DC.

All models feature user selectable 2-stage or 3-stage charging profiles, temperature compensation and user initiated equalization for optimum charging and maximum battery life.

Function	Battery Charger
Conversion	DC to DC
Power Level	300
Input Volts	40 - 60 VDC
Output Volts	12 VDC
Output Amps Continuous	20
Input/Output Isolation	Yes
Technology	Analog
Charging Stages	3
Temperature Compensation	Yes
Equalize	Yes
Battery Banks	3
Product Series on website	BCD315
Option Codes	'Z' No Conformal Coating (Any Model), 'Y' IP67 Certified, 'X' Ruggedized & Wide Temp, 'W' IP66 Water Resistant, 'V' Digital Volt/Ammeter, 'U' Safety Special Inspection (CSA/UL), 'P' Portable (Handle & Feet), 'O' Open Frame - No chassis, 'M' Military Rugged, 'J' MIL810 Tested Only, 'I' MIL461 Tested Only, 'G' GMDSS (DVAM & RCP1 Remote), 'E' European ROHS compliant, 'C' MIL461F & MIL810G Tested
