The images shown are for illustration purposes only and may not be an exact representation of the product

Outback Power, DIN-15D-AC, 15 Amp 120/240 VAC 50/60 Hz dual pole 1.0" (26 mm) wide. Branch Circuit Rated 10k AIC

  • Model: DIN-15D-AC
  • Manufactured by: Outback Power
  • Condition: New
  • Estimated Delivery: Nov 23rd - Nov 29th
  • In Stock
Price:

$64.90 $49.92

Manufacturer Info

(image for) Outback Power
DIN rail mount with set-screw compression terminals, #14 to 2 AWG (1.62 mm to 6.54 mm

Product Highlights
  • DIN rail mountable
  • Can be used for DC sources, inverters or load circuits
  • Contact OutBack for additional information
DIN-15-AC 15 Amp 120Vac 50/60Hz single pole 0.50 (13 mm) wide. Branch Circuit Rated 10k AIC
DIN-15D-AC 15 Amp 120/240Vac 50/60Hz dual pole 1.0 (26 mm) wide. Branch Circuit Rated 10k AIC
DIN-20-AC 20 Amp 120Vac 50/60Hz single pole 0.50 (13 mm) wide. Branch Circuit Rated 10k AIC
DIN-20D-AC 20 Amp 120/240Vac 50/60Hz dual pole 1.0 (26 mm) wide. Branch Circuit Rated 10k AIC
DIN-25D-AC 25 Amp 120/240Vac 50/60Hz dual pole 1.0 (26 mm) wide. Branch Circuit Rated 10k AIC
DIN-10-AC-277 10 Amp 277Vac 50/60Hz single pole 0.5 (13 mm) wide
DIN-15-AC-277 15 Amp 277Vac 50/60HZ Single Pole  0.5 (13 mm) wide
DIN-30-AC-277 30 Amp 277Vac 50/60Hz Single Pole  0.5 (13 mm) wide
DIN-30D-AC-480 30 Amp 277/480Vac 50/60Hz Dual Pole  1.0 (26 mm) wide
DIN-30T-AC-480 30 Amp 277/480Vac 50/60Hz Three Pole 1.5 (39 mm) wide
DIN-50-AC-277 50 Amp 277Vac 50/60Hz Single Pole  0.5 (13 mm) wide
DIN-50D-AC-480 50 Amp 277/480Vac 50/60Hz Dual Pole 1.0 (26 mm) wide
DIN-50T-AC-480 50 Amp 277/480Vac 50/60Hz Three Pole 1.5 (39 mm) wide
DIN-60-AC-277 60 Amp 277Vac 50/60Hz Single Pole 0.5 (13mm) wide
DIN-60D-AC-480 60 Amp 277/480Vac 50/60Hz Dual Pole 1.0 (26mm) wide
