The images shown are for illustration purposes only and may not be an exact representation of the product

Analytic Systems, BCD120-24-12, 5A, 12V Out, 22-30V In, Isolated Battery Chargers

Model: BCD120-24-12
Manufactured by: Analytic Systems
Condition: New
Estimated Delivery: Apr 4th - Apr 10th
Estimated Delivery: 2 to 3 Weeks
In Stock
Out of Stock
Built to Order - This Product Cannot Be Cancelled Once Order Is Placed

Price:

$741.49 $570.38

Manufacturer Info

Other products

Features

Ultra-quiet
Charge Batteries and Power sensitive electronics without interference
Rugged and reliable to ensure years of safe and trouble free operation
Versatile design with wide variation of input and output combinations
Precision linear regulator final stage for ultra clean output
Extremely rugged and suited for marine and other demanding environments
High tolerance for shock and vibration
Ultra-quiet low EMI operation
Ideal for running 24V PLC controls from 12 VDC
Reverse input protection
Short circuit protection
Five year parts and labour warranty

The BCD120 Series of Isolated Battery Chargers are variable duty cycle switching power supplies with precision linear regulator outputs. They can be configured to run from a 12V, 24V or 48VDC battery system to provide input/output voltages as shown below.

Applications include running 24V PLC controls from a 12 Volt battery system, or any other application requiring 24 VDC when only 12 VDC is available or to provide ground isolation between two 12 VDC or 24 VDC power systems, or between a 12 VDC and 24 VDC power system.

Function	Battery Charger
Conversion	DC to DC
Power (Watts)	120
Input Volts	22 – 30 VDC
Output Volts	12 VDC
Output Amps Continuous	5
Input/Output Isolation	Yes
Technology	Analog
Product Series on website	BCD120
Option Codes	OPT-D: Paralleling Diodes, OPT-H: High Output, OPT-U: Safety Special Inspection (CSA/SPE-1000), OPT-X: Ruggedized & Wide Temp
Specialization	Commercial/Industrial
