Polarised Product
- 300 Vdc, 1 Pole & 2 Pole; (300 Vdc per Pole)
- 400 Vdc, 4 Pole (2 Pole in series + 2 Pole in series)
- 600 Vdc, (2 Pole in series)
- Verify approvals
- CBI ROHS Statement of Compliance | Download
- CBI YA Datasheet 2023 | Download
- Telecom / datacom
- DC circuit protection
- UPS equipment
- Alternative energy equipment
- Battery protection
- High energy DC circuit breaker
- Ultra compact - 13 mm wide module
- Hydraulic-magnetic technology
- Can be switched on immediately after tripping
- YAD - DIN mount, 45 mm front escutcheon (Grey)
- YAM - DIN mount, 57 mm front escutcheon (Black)
- YAK - Dual (Din & Mini) mount, 57 mm front escutcheon (Black)
- ON and OFF indication
- Suitable for electrical isolation
- 100 % rating capability, independent of ambient temperature
- RoHS compliant
- Box type main terminals
- Auxiliary switch
- AC and DC voltages
- IEC 60947-5-1 (6 A 250 Vac, 0.5 A 110 Vdc)
- GB 14048.5 approved
- Factory fitted
- Attached to right hand side of circuit breaker
- Compact 6.5 mm width
