• Bolt, Flange, Serrated, 3/8In-16 X 2-3/4In, 1/2In Trim Head, 1.2In Thread, Black, SS x 1
• Snapnrack, Rl Universal, Bonding Clip x 1
• Snapnrack, Rl Universal, Mount Top, Black x 1
• Snapnrack, Rl Universal, Mount Spring, SS x 1
• Snapnrack, Module Clamp, Tower, Rock-In x 1
• 5-16In x 3-4In Ss Flat Washer x 1
• Bolt, Flange, 5-16In-18 X 3-4In, Clear, SS x 1
• Snapnrack, Angle Brkt, 90 Deg, 1In Slot, 25 Deg Fastener x 1
• Snapnrack, Base, Comp Roof, Deck Mount, Speedseal x 1
• Bolt, Flanged Hex, 5-16In-18 X 1-1-4In, SS x 1
• Snapnrack, Channel Nut, 5-16In-18, 25 Deg Fastener x 1
• Snapnrack, Sealing Washer Wood Screw, #14 X 2-1-4In, 1-2 In Hex Head, SS x 4
• Product Specifications | Download

• Materials: Aluminium, Stainless Steel
• Design Load (Lbs): 210 Lbf Up, 320 Lbf Down, 162 Lbf Side
• Ultimate Load (Lbs): 630 Lbf Up, 960 Lbf Down, 486 Lbf Side
• Torque Specification: See Installation Manual Ft-Lbs
• Certification: Ul2703
• Weight (Lbs): 1.1
