MidNite 500amp battery combiner box Includes a 500amp Positive and Negative bus bar with 3/8 inch studs. Cables can be double lugged and the copper bus bar can be drilled for additional mounting locations, We recommend you use 3/8 inch stainless bolts if you drill holes to attach more ring terminals.

500amp 50mv shunt optional "MNSHUNT"
Third bus bar optional "MNBCB-BUSBAR500"
Has locations for up to 20 of the 3/4 inch wide and 4 of the 1.5 inch wide MNEDC breakers
Powder Coated Steel
Max. AC Voltage - 277VAC
Max. DC Voltage - 300VDC
Max. Wire Size - 4/0
Number of Spaces - 24
Environment Rating - Type 1 environmental rating (indoor)
Warranty - 5yrs
Made in USA
California Residents: Warning

• MNBCB500-50_REV-D_BATTERY_COMBINER_5 3.9.23 | Download
• MNBCB500-50_REV-D_BATTERY_COMBINER_4 3.9.23 | Download
