May be suitable for use when military specifications are required under CFR 46.
| Specifications | |
|---|---|
| Amperage | 5A |
| Actuator Style Flat actuator resists accidental switching by being flush in the ON position Raised rocker actuator standard circuit breaker for AC Source Select panels in the 360 Panel System Restricted OFF actuator can only be switched to OFF by insertion of small screwdriver into slot Toggle actuator An electric switch operated by means of a projecting lever that is moved up and down. | Metal Toggle |
| Poles | 2 |
| Maximum Voltage | 277V AC65V DC |
| Circuit Breaker Type | Magnetic Hydraulic—Trip free |
| Interrupt Capacity | 1500A AC7500A DC |
| Minimum Operating Temperature | -40° C |
| Maximum Operating Temperature | 85° C |
| Mounting Boss | 1/2-32 Hex Nut SS |
| Mounting Nut Torque | 30in-lb (3.39 Nm) |
| Mounting Screw | #6-32 SS |
| Mounting Screw Torque | 7 in-lb (0.79 Nm) |
| Screw Terminal Torque | 14 in-lb (1.58 Nm) |
| Switching Cycles | 6000 Electrical4000 Mechanical |
| Terminal Screws | #10-32 SS |
| Weight | 0.13lb (0.06 kg) |
