Simpliphi, PHI-1.4-12-60, 1.4 kWh, Deep-Cycle Lithium Ferro Phosphate Battery, 12V

  • Model: PHI-1.4-12-60
  • Manufactured by: SimpliPhi
  • Condition: New
  • Estimated Delivery: 1 to 2 Weeks
  • Lead Time To Ship May Vary
Price:

$1,607.34 $1,236.42

Manufacturer Info

PHI 1.4 Battery

The PHI 1.4 kWh 60 Amp deep-cycle Lithium Ferro Phosphate (LFP) battery is optimized with proprietary cell architecture, power electronics, BMS and assembly methods. It is modular, lightweight and scalable. Provides power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile.
CHEMISTRY Lithium Ferro Phosphate (LFP) The safest Lithium Ion chemistry available No cobalt, risk of thermal runaway or fire
BMS Built-in Battery Management System
CONNECTORS Built-in SB50 Anderson Connector
COMPATIBILITY Compatible with all industry standard inverters and charge controllers Battery bank-to-inverter output sizing must adhere to a 2:1 ratio: battery quantity inverter kWAC rating/ inverter efficiency) / battery MAX Continuous Discharge Rate in kWDC
MAINTENANCE Maintenance-free No ventilation, cooling or thermal regulation required
PHI 1.4 12V 24V
DC Voltages - Nominal 12.8VDC 25.6VDC
Amp-Hours 115 Ah 57 Ah
Rated kWh Capacity @ C/2 1.4 kWh DC @ 100% DOD 1.12 kWh DC @ 80% DOD 1.4 kWh DC @ 100% DOD 1.12 kWh DC @ 80% DOD
MAX Discharge Rate (10 minutes) 60 Amps DC (0.76 kW DC) 60 Amps DC (1.53 kW DC)
MAX Continuous Discharge Rate 40 Amps DC (0.51 kW DC) 28.5 Amps DC (0.73 kW DC)
MAX Continuous Charge Rate 40 Amps DC (0.51 kW DC) 28.5 Amps DC (0.73 kW DC)
DC Voltage Range1 12 VDC to 14 VDC 24 VDC to 28 VDC
Depth of Discharge1 up to 100% up to 100%
Operating Efficiency 98% 98%
Charge Temperature1 32 to 120F (0 to 49C) 32 to 120F (0 to 49C)
Operating Temperature1 -4 to 140F (-20 to 60C) -4 to 140F (-20 to 60C)
Storage Temperature1 6 months: 14 to 77 F (-10 to 25 C) 3 months: -4 to 113 F (-20 to 45 C) 6 months: 14 to 77 F (-10 to 25 C) 3 months: -4 to 113 F (-20 to 45 C)
Self-Discharge Rate <1% loss per month <1% loss per month
Cycle Life 10,000+ (@80% DOD) 10,000+ (@80% DOD)
Memory Effect None None
Warranty Period 10 Years 10 Years
Weight 33.28 lbs (15.1 kg) 33.28 lbs (15.1 kg)
Dimensions 11.25 x 9.25 x 6.25 inches/0.37 ft3 (23.495 x 28.575 x 15.875 cm/0.010m3) 11.25 x 9.25 x 6.25 inches/0.37 ft3 (23.495 x 28.575 x 15.875 cm/0.010m3)
