Victron Energy, VEP250125402, VE Panel 5kVA 120/240 NA Primary 48Vdc
Manufacturer Info
Includes
- Internally pre-wired enclosure.
- A built-in AC bypass switch with full system current capability, and a DC disconnect breaker for safe and easy isolation for servicing of the inverter and/or battery bank.
- Battery to inverter/charger DC disconnect breaker (250 Amps).
- Inverter AC input overcurrent protection breakers.
- DIN mount AC and DC breakers for quick and easy operation.
- A500A/50mV DC shunt installed for easy connection to battery status monitor.
- Enclosure and components are UL/CSA certified and designated for indoor use.
- Configurations available for both single 120 and 230 VAC, 120/240 VAC and 3-Phase systems.
- DC negative, positive and ground busbars for DC loads and PV arrays included.
- Mounting provided for DIN rail DC load/disconnect breakers.
- Integrates directly with Victron Energy’s 3,000 and 5,000 MultiPlus and Quattro inverter/chargers.
- Knockouts for inverter/charger and battery cables, PV in/out, DC panel mount breakers.
- Victron Electrical Panel Installation and Service Manual | Download
- The VE Panel (VEP) is designed for the 3kVA and 5kVA MultiPlus and Quattro inverter/chargers.
| Description | Part Number |
| VE Panel 3kVA 120/240 NA Primary 24/48Vdc | VEP230121402 |
| VE Panel 3kVA 120 NA Follower 24/48Vdc | VEP230141204 |
| VE Panel 3kVA NA 3PH Primary 24/48Vdc | VEP230161604 |
| VE Panel 3kVA 230 Export Primary 24/48Vdc | VEP230422002 |
| VE Panel 3kVA 230 Export Follower 24/48Vdc | VEP230442004 |
| VE Panel 3kVA 230 Export 3PH 24/48Vdc | VEP230462206 |
| VE Panel 5kVA 120/240 NA Primary 48Vdc | VEP250125402 |
| VE Panel 5kVA 120 NA Follower 48Vdc | VEP250145204 |
| VE Panel 5kVA NA 3PH Primary 48Vdc | VEP250165606 |
| VE Panel 5kVA 230 Export Primary 48Vdc | VEP250426002 |
| VE Panel 5kVA 230 Export Follower 48Vdc | VEP250446004 |
| VE Panel 5kVA 230 Export 3PH 48Vdc | VEP250466206 |
