(image for) NorthStar, NSB40FT BLUE+, BLUE+ VRLA-AGM Pure Lead Carbon 37Ah, 12V Front Terminal, kWh Storage Per Battery: 0.44 kWh Nameplate / 0.22 kWh Effective

The images shown are for illustration purposes only and may not be an exact representation of the product

NorthStar, NSB40FT BLUE+, BLUE+ VRLA-AGM Pure Lead Carbon 37Ah, 12V Front Terminal, kWh Storage Per Battery: 0.44 kWh Nameplate / 0.22 kWh Effective

Model: NSB40FT BLUE+
Manufactured by: Northstar
Condition: New
Estimated Delivery: Nov 22nd - Nov 28th
In Stock
Out of Stock

Price:

$423.99 $326.14

Product Has A Minimum Order Quantity: 12

Manufacturer Info

Other products

The NSB BLUE+ Battery delivers ultra fast recharge and exceptional PSoC cycling performance.

Exceptional PSoC cyclic performance 2050 cycles @50% DoD
Design life 12+ years at 20C (68F)
EUROBAT design life definition: Very Long Life (12+ years)
Ultra fast recharge
Shelf life of up to 24 months
High modulus Polyphenylene Oxide (PPO) plastic materials designed to withstand extended elevated operating temperatures and maintain high battery compression essential for reliable operation
Flame retardant (UL 94 VO) and LOI of at least 28%
Lead carbon added to negative electrodes increases power and reduces sulfation
High potential fuel savings when used with hybrid genset applications
Operating temperature range -40C to +65C (-40F to 149F)
State-of-the-art automated manufacturing ensures consistency and reliability
Advanced 3 stage terminal design to ensure leak-free operation - brass terminals provide maximum performance
Non-halogenated thermally sealed plastic casing
Approved as non-hazardous cargo for ground sea and air transport DOT 49CFR173.159(d), (i) and (ii)
Product Datasheet | Download

Terminal

Female M6 x 1.0

Terminal torque

8.0 Nm (71 in-lbs)

10 hr capacity to 1.80VPC @ 25C (77F)

37 Ah

8 hr capacity to 1.75VPC @ 25C (77F)

37 Ah

Float voltage @ 20/25C (68/77F)

2.28 / 2.27 VPC

Impedance (1Khz)

3.9 m? @ 25

Terminal	Female M6 x 1.0
Terminal torque	8.0 Nm (71 in-lbs)
10 hr capacity to 1.80VPC @ 25C (77F)	37 Ah
8 hr capacity to 1.75VPC @ 25C (77F)	37 Ah
Float voltage @ 20/25C (68/77F)	2.28 / 2.27 VPC
Impedance (1Khz)	3.9 m? @ 25C (77F)
Conductance	1114 S
Short circuit current	1500 A
Maximum charge current (A)	No Limit
Operation temperature range	-40C to +65C
Nominal voltage	12 V

C (77F)
