IQ Gateway (IEEE certified)

The Enphase IQ Gateway delivers solar production and energy consumption data to Enphase Installer Platform for comprehensive, remote maintenance and management of the Enphase IQ System.

With revenue grade production metering, optional consumption monitoring, and seamless integration with the Enphase IQ Battery, the IQ Gateway is the platform for total energy management.

The Enphase IQ Gateway comes with integrated revenue grade PV production metering (ANSI C12.20 +/- 0.5%) and optional consumption monitoring (+/- 2.5%). It also includes one 200A continuous rated production CT.

• Designed for installation indoors or outdoors
• Easy system configuration using Enphase Installer App
• Bidirectional communications for remote upgrades
• Supports power export limiting and zero export applications
• Flexible networking with Wi-Fi, Ethernet, or cellular
• 5-year warranty
• ENV2-IQ-AM1-240 complies with IEEE 1547:2018 (UL 1741-SB, 3rd Ed.)
• IQ Gateway data sheet | Download

Technical Specifications

• 200 A Continued rated production CT
• 120/240 VAC split-phase power
• 802.11B /G /N integrated wi-fi
• Typical power consumption: 5 W
• Capacity: Up to 600 Microinverters

Compatibility

• IQ series microinverters
• Q cables
• IQ battery system

Whats in the box

• 1 IQ Gateway
• 1 200 A continuous rated production Current Transformer (CT)

Length	45.00 mm
Width	213.00 mm
Height	126.00 mm
Weight	1.10 lbs
