Blue Sea Systems, 3120, SMS Surface Mount System Panel Enclosure - 240V AC / 50A ELCI Main - For Isolation Transformer

  • Model: 3120
  • GTIN: 00632085031206
  • Manufactured by: Blue Sea Systems
  • Condition: New
  • Estimated Delivery: 1 to 2 Weeks
  • Lead Time To Ship May Vary
Price:

$1,069.07 $822.36

Manufacturer Info

Panel enclosure for ELCI Main circuit breakers and otherlarge frame devices. Meets ABYC E-11 when used with anELCI Main circuit breaker and mounted within 10 feet ofthe shore power inlet

Features
  • Blank apertures for custom breaker loading
  • Glass filled polycarbonate base
  • Clear cover allows easy view of circuit breaker status
  • Overlapping cover for strength and increased gasket protection
  • Oversized, formed in place seamless PUR gasket
  • Easily removable stainless steel hinge pin for unobstructed installation
  • Stainless steel latch secures cover without penetrating the enclosure
  • Blank circuit positions accommodate Carling TechnologiesA and C Series Flat Rocker and ELCI Main circuit breakers
  • Stainless steel mounting hardware included
  • Includes waterproof glands
  • Green LEDs for backlighting and ON indication
  • Instructions
  • Wiring Diagram
Specifications
Minimum Operating Temperature-40 C
Maximum Operating Temperature85 C
Cover Screws and Hardware10-32 Stainless Steel
Enclosure Size6.0" x 6.0" x 4.0"(152mm x 152mm x 102mm)
Exterior Overall Dimensions7.6" x 7.4" x 4.7"(192mm x 188mm x 120mm)
Mounting Hardware1/4" Diameter, #12 (6 mm)
Included
QtyPNProduct
14206Basic AC Label Kit - 30 Black Square Labels
13125SMS Enclosure Gland PG16
13093C-Series ELCI Circuit Breaker - Double Pole 240V AC 50A (MAIN)
