The images shown are for illustration purposes only and may not be an exact representation of the product

Analytic Systems, VCH10-48, 10A, 48V Out, 60-80V In, Non-Iso DC/DC Voltage Converter

Model: VCH10-48
Manufactured by: Analytic Systems
Condition: New
Estimated Delivery: Oct 31st - Nov 6th
Estimated Delivery: 2 to 3 Weeks
In Stock
Out of Stock
Built to Order - This Product Cannot Be Cancelled Once Order Is Placed

Price:

$333.45 $256.50

Manufacturer Info

Other products

Features

"Output ON" and "Overload" LED indicators
Compact size and easy mounting
Up to 80V input
Simple plug in wiring
Paralleling diodes available (Option D)
Ruggedized for vibration and wide temperature range available (Option X)
Watertight versions available (Option W = IP66; Option Y = IP67)
Custom output voltages available
Five year parts and labour warranty
Product Datasheet | Download
Product Manual | Download

The VCH10 Series of Step-Down Voltage Converters supply up to 10 amps of output current at 12, 24, 36 or 48 volts from any higher voltage between 20 and 80 volts DC. For automotive, heavy equipment, marine, industrial, rail or alternative energy environments.

All surface mount high frequency design offers higher reliability, higher efficiency (more than 92%), more power (up to 544 watts at 48 VDC Out) and minimum size.

The unit has reverse input protection, output current limiting and output over-voltage protection.

Function	Voltage Converter
Conversion	DC to DC
Power Level	480
Input Volts	60 - 80 VDC
Output Volts	48 VDC
Output Amps Continuous	10
Input/Output Isolation	No
Technology	Analog
Product Series on website	VCH10
Option Codes	'Z' No Conformal Coating (Any Model), 'Y' IP67 Certified, 'X' Ruggedized & Wide Temp, 'W' IP66 Water Resistant, 'V' Digital Volt/Ammeter, 'O' Open Frame - No chassis, 'N' Encapsulated, 'M' Military Rugged, 'J' MIL810 Tested Only, 'I' MIL461 Tested Only, 'F' Electric Fork Lift, 'E' European ROHS compliant, 'D' Paralleling Diodes, 'C' MIL461F & MIL810G Tested
