Convert Battery Power to Household AC Power
- Run your household appliances in your truck, boat or RV
- Powerful and economical modified sinewave inverters
- Tested and approved to cETLus regulatory standards for North America
- Tested and approved to CE regulatory standards for Europe
- International output sockets available
- Ideal for cars, boats, trucks, and RVs
- Regulated output
- Low battery shutdown to prevent total battery discharge
- Built in LED display for unit status
- Over temperature shutdown
- Simple to install
- Compact size for easy storage
- Product Specifications | Download
- Product Manual | Download
- MW 1204: 4 x 6 x 2 (102 x 152 x 51 mm)
- MW 1204: 1.6lb (0.73kg)
| MW Series (Modified Sinewave) | MW 1204 |
|---|---|
| AC Output | |
| Power (Continuous) | 400W |
| Power (Peak) | 800W |
| Voltage / Frequency | 120 VAC / 60 Hz |
| Current | 3.3A |
| Waveform | Modified Sinewave |
| Peak Efficiency | 90% |
| AC Output Socket | NEMA 5-15 |
| DC Output | |
| 5V USB | N/A |
| DC Input | |
| Voltage (nominal) | 12.5Vdc |
| Operation Range | 10.5 – 15.5Vdc |
| Current (no load) | < 0.3A |
| Display Panel | |
| Indicator (LED) | Power, Fault |
| Digital Display | N/A |
| Protection | |
| Input Undervoltage Shutdown | 10.5Vdc |
| Input Overvoltage Shutdown | 15.5Vdc |
| Regulatory Compliance | |
| Markings | cETLus |
| Conformance | UL & CSA Standards |
| Enclosure | |
| Weight | 1.6 lbs |
| Dimension | 4 x 6 x 2" |
