Latest V8 version Bluetooth BMS, top battery cells balance function.

Bluetooth&Built-in Heater Function SK12V206H designed for cold weather using! Can safely charge at temperatures down to -20C (-4F) by a standard charger or solar charger. The heater pads which draws power from the charger itself,battery cells no power lost.

Description

• 7 Years Warranty,3000~8000 Cycles Life Span,Free Maintenance. Detachable Cover,Replaceable BMS or Cells.
• Connect in series for 24V or 36V or 48V Battery Bank, or Connect in Parallel for Larger Capacity.
• Built-in Smart Battery Management System.
• Low Temperature Charging Cut-off.
• High Temperature Charging or Discharging Cut-off.
• Over Charging or Discharging Protection.
• Over Current & Short Circuit Protection.
• Battery Cells Auto Balance.
• Notice for connect in series: If you need connect batteries in series, they should be at the same state-of-charge (SOC)before they are connected.
• SK12V206P.pdf | Download
• SOK BATTERY MANUAL 2(1).pdf | Download

Charge information

• Recommended Charge Current 40 A
• Maximum Charge Current 70 A
• Recommended Charge Voltage 14.6 V

Discharge Information

• Maximum continuous discharge current: 170A
• Peak discharge current: 200A(3 seconds)
• Recommend low voltage disconnect: 11.2V
• BMS discharge cut-off voltage: Around 10.4V
• Reconnect Voltage:>11.6V

Size Information

• Terminal Type: M8, 5/16 lugs
• Weight: 48 lbs.

Temperature Information

• Discharge temperature:-4F~140F
• Charge temperature: 32F~113F
• Recommend storage temperature:23F~95F

Certifications Information

• UL1973&IEC62619 for Battery cells.
